Frame
800 Series OCLV Carbon, IsoSpeed, hidden mudguard mounts, integrated frame bag mounts, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle
Fork
Checkmate SLR full carbon, tapered carbon steerer, hidden mudguard mounts, flat-mount disc, 12x100 mm thru axle
Wheel Front
Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25 mm rim width, 100 x 12 mm thru axle
Wheel Rear
Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25 mm rim width, SRAM XD-R driver, 142x12 mm thru axle
Skewer Front
Bontrager Switch chamfered thru axle, removable lever
Skewer Rear
Bontrager Switch chamfered thru axle, removable lever
Tyre
Bontrager Girona RSL GR, Tubeless-Ready, aramid bead, 220 tpi, 700x38 mm
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
45 mm without mudguards
Battery
SRAM eTap battery pack (with charger)
Shifter
SRAM RED eTap AXS, 12-speed
Rear Derailleur
SRAM RED XPLR eTap AXS, 44T max cog
Crank Size XS, S
SRAM RED AXS w/ power meter, 40T, DUB, 165 mm length
Crank Size M
SRAM RED AXS w/ power meter, 40T, DUB, 170 mm length
Crank Size ML, L
SRAM RED AXS w/ power meter, 40T, DUB, 172.5 mm length
Crank Size XL
SRAM RED AXS w/ power meter, 40T, DUB, 175 mm length
Bottom Bracket
SRAM DUB, T47 threaded, internal bearing
Cassette
SRAM XG-1271, 10-44, 12-speed
Chain
SRAM RED D1, 12-speed
Max. Chainring Size
See service manual
Saddle Size XS, S
Bontrager Aeolus P2 Pro, carbon rails, 155 mm width
Saddle Size M, ML, L, XL
Bontrager Aeolus Pro, carbon rails, 145 mm width
Seatpost Size XS, S, M
KVF aero carbon seat post, 5 mm offset, 280 mm length
Seatpost Size ML, L, XL
KVF aero carbon seat post, 5 mm offset, 320 mm length
Handlebar/Stem Size XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 70 mm stem length
Handlebar/Stem Size S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 80 mm stem length
Handlebar/Stem Size M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length
Handlebar/Stem Size ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 100 mm stem length
Handlebar/Stem Size XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length
Brake Rotor
SRAM CentreLine X, CentreLock, round edge, 160 mm
Rotor Size
Max brake rotor sizes: 180mm front and rear
Weight
ML – 8.00 kg/17.64 lb (with TLR sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
