Frameset
Frame
Premium Alpha Platinum Aluminium frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork
SR Suntour XCR32, tapered steerer tube, coil spring, preload adjuster, lockout,100mm QR, 80mm travel
Wheels
Hub front
Shimano Tourney HB-QC300, centerlock
Hub rear
Shimano TC500-HM
Skewer rear
Bontrager Switch thru axle, removable lever
*Rim
Size: S, M, L, XL. Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size: S, M, L, XL. Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Connection Elite, reflective strip, wire bead, 60 tpi, 27.5x2.40"
Max tyre size
Frame: 27.5x2.40", Fork: See manufacturer
E-system
Battery
Bosch PowerTube 540 Wh
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
E-bike Classification
Class 1
Drivetrain
Crank
ProWheel alloy, 170 mm length
Chainring
Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
Bontrager City pedals
Max. chainring size
1x: 50T
Components
Saddle
Bontrager Commuter Comp
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Bontrager alloy, 31.8mm, 5mm rise, 720 width
Grips
Trek Ergonomic Comp, lock-on
Stem
Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 80mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano EM300, CentreLock, 180 mm
Rotor size
Max brake rotor sizes - Frame: 203 mm, Fork: see fork manufacturer
Accessories
*Light
Size: S, M, L, XL. Trek LED, taillight
Size: S, M, L, XL. Trek LED, 400 lumen low/800 lumen high, headlight
Kickstand
Pletscher Comp Flex 40
Weight
Weight
M - 27.80 kg / 61.29 lb (excluding battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
Due to supply chain issues, compatible parts may be substituted at any time without notice.
