Frameset
Frame
Premium Alpha Platinum Aluminium frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork
SR Suntour XCR32, tapered steerer tube, coil spring, preload adjuster, lockout,100mm QR, 80mm travel
Wheels
Hub front
Shimano Tourney HB-QC300, centerlock
Hub rear
Shimano TC500-HM
Skewer rear
Bontrager Switch thru axle, removable lever
*Rim
Size: M, L, XL. Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Size: M, L, XL. Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Connection Elite, reflective strip, wire bead, 60 tpi, 27.5x2.40"
Max tyre size
Frame: 27.5x2.40", Fork: See manufacturer
E-system
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
E-bike Classification
Class 1
Drivetrain
Crank
ProWheel alloy, 170 mm length
Chainring
Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
Bontrager City pedals
Max. chainring size
1x: 50T
Components
Saddle
Bontrager Commuter Comp
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Bontrager alloy, 31.8mm, 5mm rise, 720 width
Grips
Trek Ergonomic Comp, lock-on
Stem
Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 80mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano EM300, CentreLock, 180 mm
Rotor size
Max brake rotor sizes - Frame: 203 mm, Fork: see fork manufacturer
Accessories
*Light
Size:M, L, XL. Trek LED, taillight
Size:M, L, XL. Trek LED, 400 lumen low/800 lumen high, headlight
Kickstand
Pletscher Comp Flex 40
Weight
Weight
L - 26.80 kg / 59.09 lb (excluding battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
Due to supply chain issues, compatible parts may be substituted at any time without notice.
*Please note – spec applies to all sizes unless listed separately.
