Frame
500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12 mm thru axle
Fork
Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Wheel Front
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Wheel Rear
Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, Shimano 11/12-speed freehub, 142x12 thru axle
Tyre
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32 mm
Max Tyre Size
38mm without mudguards, 35mm with mudguards
Shifter
Shimano 105 R7170, 12-speed
Front Derailleur
Shimano 105 R7150 Di2, braze-on, down swing
Rear Derailleur
Shimano 105 R7150 Di2, 36T max cog
Crank Size 44, 47
Shimano 105 R7100, 50/34, 165 mm length
Crank Size 50, 52
Shimano 105 R7100, 50/34, 170 mm length
Crank Size 54, 56
Shimano 105 R7100, 50/34, 172.5 mm length
Crank Size 58, 60, 62
Shimano 105 R7100, 50/34, 175 mm length
Bottom Bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano 105 7101, 11-34, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max Chainring Size
1x: 48T, 2x: 52/36
Saddle Size 44, 47, 50, 52
Verse Short Comp, steel rails, 155 mm width
Saddle Size 54, 56, 58, 60, 62
Verse Short Comp, steel rails, 145 mm width
Seatpost Size 44, 47, 50, 52, 54, 56
KVF aero carbon seat post, 20 mm offset, 280 mm length
Seatpost Size 58, 60, 62
KVF aero carbon seat post, 20 mm offset, 320 mm length
Handlebar Size 44, 47
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 36 cm width
Handlebar Size 50
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 38 cm width
Handlebar Size 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 40 cm width
Handlebar Size 54, 56
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 42 cm width
Handlebar Size 58, 60, 62
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 44 cm width
Handlebar Tape
Bontrager Supertack Perf tape
Stem Size 44
Trek RCS Pro, -7-degree, 60 mm length
Stem Size 47
Trek RCS Pro, -7-degree, 70 mm length
Stem Size 50
Trek RCS Pro, -7-degree, 80 mm length
Stem Size 52, 54
Trek RCS Pro, -7-degree, 90 mm length
Stem Size 56, 58
Trek RCS Pro, -7-degree, 100 mm length
Stem Size 60, 62
Trek RCS Pro, -7-degree, 110 mm length
Brake Rotor
Shimano RT70, CentreLock, 160 mm
Rotor Size
Max brake rotor sizes: 160 mm front and rear
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb)
