Frame
OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post-mount brake, Boost148
Fork
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15 mm Maxle Stealth, 100 mm travel
Max compatible fork travel
110mm (515 axle-to-crown)
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Rim
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tyre
Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20"
Tyre part
Size: S/M/ML/L/XL/XXL, Bontrager TLR sealant, 180 ml/6 oz
Size: S/M/ML/L/XL/XXL, Bontrager TLR valve, 50 mm
Max tyre size
Frame: 29x2.40" Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, long cage
Crank
Size: S/M, Shimano MT511, 30T steel ring, Boost, 170 mm length
Size: M/ML/L/XL/XXL, Shimano MT511, 30T steel ring, Boost, 175 mm length
Bottom bracket
Shimano MT500, 92 mm, PressFit
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100
Max. chainring size
36T, Min 30T
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: S, Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M, Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: ML/L/XL/XXL, Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: S/M/ML, Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width
Size: L/XL, Bontrager Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width
Size: XXL, Bontrager Line, alloy, 35 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Size: S, Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 60 mm length
Size: M/ML, Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 70 mm length
Size: L/XL, Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 80 mm length
Size: XXL, Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 13-degree, 90 mm length
Size: XXL, Bontrager Elite, 35 mm, 0-degree, 90 mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Size: S/M/ML/L/XL/XXL, Shimano RT26, 6-bolt,160 mm
Size: L/XL/XXL, Shimano RT26, 6-bolt,180 mm
Weight
M - 25.66 lbs / 11.64 kg (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
