Frame
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
Fork
Size: XS, RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: S, RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M/ML/L/XL/XXL, RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Front hub
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Rear hub
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Size: XS/S, Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"
Size: M/ML/L/XL/XXL, Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
Shifter
Shimano Deore M4100, 10 speed
Rear derailleur
Shimano Deore M5120, long cage
Crank
Size: XS/S/M, FSA Alpha Drive, 28T steel ring, Boost, 170 mm length
Size: ML/L/XL/XXL, FSA Alpha Drive, 28T steel ring, Boost, 175 mm length
Bottom bracket
FSA, 73 mm, threaded cartridge, 122.5 mm spindle
Cassette
Shimano Deore M4100, 11-46, 10-speed
Chain
KMC X10, 10-speed
Pedal
VP-536 nylon platform
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: XS/S/M, Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: ML/L/XL/XXL, Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: XS, Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S/M/ML/L/XL/XXL, Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Size: XS, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Size: S, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: M, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: ML/L, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: XL/XXL, Bontrager alloy, 31.8 mm clamp, Blendr-compatible, 7-degree, 90 mm length
Head set
Semi-integrated, 1-1/8"
Brake
Shimano MT200 hydraulic disc
Brake rotor
Size: XS/S/M/ML/L/XL/XXL, Shimano RT26, 160 mm, 6-bolt
Size: L/XL/XXL, Shimano RT26, 180 mm, 6-bolt
Weight
M - 13.77 kg / 30.35 lbs (with tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
