Frameset
FrameAlpha Platinum Aluminium, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, E2 tapered head tube, Mino Link, Control Freak internal routing, downtube guard, PF92, ISCG 05, G2 Geometry, 130 mm travel
Front suspensionFox Rhythm 34 Float, GRIP adjustable damper, E2 tapered steerer, G2 Geometry w/51 mm offset, Boost110, 130 mm travel
Rear suspensionFox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210x52.5 mm
Wheels
WheelsBontrager Line Comp 30, Tubeless Ready, 54T Rapid Drive, Boost110 front, Boost148 rear, tubeless strips included, valves sold separately
TyresBontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120tpi, aramid bead, 29x2.40˝
Drivetrain
ShiftersSRAM GX Eagle, 12-speed
Rear derailleurSRAM GX Eagle, Roller Bearing Clutch
CrankSRAM Descendant 6k Eagle, 32T Direct Mount X-Sync
Bottom bracketPF92
CassetteSRAM XG-1275, 10-50, 12-speed
ChainSRAM GX Eagle
PedalsNot included
Components
SaddleBontrager Evoke 2, chromoly rails
SeatpostBontrager Drop Line, internal routing, 31.6 mm (15.5: 100 mm/17.5 & 18.5: 125 mm/19.5 & 21.5: 150 mm)
HandlebarBontrager Line, 35 mm, 15 mm rise, 750 mm width
GripsBontrager Race Lite, lock-on
StemBontrager Line, Knock Block, 35 mm clamp, 0-degree, 60 mm length
Head setKnock Block Integrated, sealed cartridge bearing, 1-1/8˝ top, 1.5˝ bottom
Brake setSRAM Guide R hydraulic disc
Weight
Weight17.5" - 14.11 kg / 31.10 lbs (with tubes)
Weight limitThis bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
