Frameset
Frame Alpha Silver Aluminium, 24"
Fork Wahoo 24" carbon, post-mount disc brake, ThruSkew 5 mm QR
Wheels
Hub front Formula DC-20, alloy, 6-bolt, 100 mm
Skewer front 135x5 mm bolt-on
Hub rear Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
Skewer rear 169x5 mm bolt-on
Rim Alloy 24'', 28H
Tyre Kenda Amrak, 30 tpi, 24x2.20"
Max tyre size 24x2.40" with or without mudguards
Drivetrain
Shifter microSHIFT Advent Quick Trigger Pro SL-M6295, 9-speed
Rear derailleur microSHIFT Advent RD-M6195M, 40-46T max cog
Crank Alloy, 30T steel chain ring w/ guard. 127 mm length
Bottom bracket Sealed cartridge, 68 mm
Cassette microSHIFT Advent H093, 11-42, 9-speed
Chain KMC X9
Pedal VP-225 nylon platform
Max. chainring size 1x: 30T
Components
Saddle Kids' padded, integrated seat post, Blendr light mount, 31.6x270 mm
Handlebar Bontrager alloy, 31.8 mm, 20 mm rise, 600 mm width
*Grips Size: 24" wheel - Kids' grip, 110 mm width. Size: 24" wheel - Kids' grip, 108 mm length
Stem Bontrager alloy, 31.8 mm clamp, 6-degree, 45 mm length
Head set Integrated, sealed cartridge bearings
Brake Tektro HD-J285 hydraulic disc
Brake rotor Tektro, 6-bolt, 160mm
Rotor size Max brake rotor sizes: 160 mm front and rear
Accessories
Mudguard Trek custom
Weight
Weight 10.50 kg / 23.15 lbs
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 175 lb (80 kg).
Due to supply chain issues, compatible parts may be substituted at any time without notice. Weights may vary in final production.
