Frame
Alpha Platinum, Removable Integrated Battery (RIB 2.0), tapered headtube, internal routing, Motor Armour, rack and mudguard mounts, ABP, Boost 148, 120 mm travel
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel
Max Compatible Fork Travel
See service manual
Hub Front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub Rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer Rear
Bontrager Switch thru-axle, removable lever
Rim (Size: S, M, L, XL)
Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Rim (Size: S, M, L, XL)
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Spokes (Size: S, M, L, XL)
14 g stainless steel, black
Spokes (Size: S, M, L, XL)
14g stainless
Tyre (Size: S)
Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre (Size: M, L, XL)
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
Battery
Bosch PowerTube 600 Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Shifter
Shimano U6000, 10-speed
Rear Derailleur
Shimano CUES U6000 GS
Crank
FSA Bosch CK-220, 36T ring, 165 mm length
Chainring
FSA, 36T, steel
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
VP-536 nylon platform
Max. Chainring Size
1x: 38T
Saddle
Bontrager Verse P3, steel rails
Seatpost (Size: S)
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost (Size: M, L, XL)
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Tektro Gemini SL 4 piston hydraulic brake
Brake Rotor
Tektro, CentreLock, 203 mm
Rotor Size
Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
