Frame
Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, flat-mount disc, kickstand mount, 144.5 mm OLD hub motor spacing
Fork
Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Skewer front
132x5 mm QR
Hub rear
Hyena hub drive motor, 40 Nm, 250 W
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm
Battery
250 Wh, integrated in down tube
Charger
2A, 42V output, 100V–240V AC input
Computer
LED display
Shifter
Shimano Altus M315, 8-speed
Rear derailleur
Shimano Acera M3020-8, 40T max cog
Crank
Size: S, M - ProWheel Pro alloy, 42T narrow-wide steel ring, 170 mm length
Size: L, XL - ProWheel Pro alloy, 42T narrow-wide steel ring, 175 mm length
Bottom bracket
Torque sensor, threaded, 122.5 mm spindle
Cassette
Shimano HG400, 11-40, 8-speed
Chain
KMC Z8.3
Pedal
Slip-proof pedals with reflectors
Saddle
Bontrager Sport
Seatpost
Size: S, M - Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: L, XL - Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: S, M - Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: L, XL - Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem
Size: S, M - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size: L, XL - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brake
Shimano hydraulic disc, MT200 lever, UR300 calliper
Brake rotor
Shimano RT26, 6-bolt, 160 mm
Light
Size: S, M, L, XL - Herrmans MR4, 120-lumen LED
Size: S, M, L, XL - Spanninga Solo
Kickstand
Pletscher Comp 18
Cargo rack
MIK-compatible alloy rear rack, maximum load 25 kg
Mudguard
Size: S, M, L, XL - SKS plastic, rear
Size: S, M, L, XL - SKS plastic, front
Weight
M - 17.75 kg / 39.14 lb
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
