Frameset
Frame
Premium Alpha Platinum Aluminium frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork
SR Suntour SF25-NVX32, coil spring, preload adjuster, 5 mm ThruSkew, 63 mm travel
Wheels
Hub front
Shimano Tourney HB-QC300, centerlock
Skewer front
Trek Thru-Skew
Hub rear
Shimano TC500-HM
Skewer rear
Bontrager Switch thru axle, removable lever
*Rim
Size: M, L, XL. Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Size: M, L, XL. Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Max tyre size
Frame: 27.5x2.40", Fork: See manufacturer
E-system
Battery
Bosch PowerTube 540 Wh
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
E-bike Classification
Class 1
Drivetrain
Shifter
Shimano U4000, 9-speed
Crank
ProWheel alloy, 170 mm length
Chainring
Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
Bontrager City pedals
Max. chainring size
1x: 50T
Components
Saddle
Bontrager Boulevard
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Trek Ergonomic Comp, lock-on
Stem
Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 80mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano EM300, CentreLock, 180 mm
Rotor size
Max brake rotor sizes - Frame: 203 mm, Fork: see fork manufacturer
Accessories
*Light
Size: M, L, XL. Trek LED, taillight
Size: M, L, XL. Trek LED, 400 lumen low/800 lumen high, headlight
Kickstand
Pletscher Comp Flex 40
Weight
Weight
L - 26.80 kg / 59.09 lb (excluding battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
Due to supply chain issues, compatible parts may be substituted at any time without notice.
*Please note – spec applies to all sizes unless listed separately.
