Frame | Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost 148, 120 mm travel |
Fork | RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel |
Shock | RockShox Deluxe Select R, 210x50 mm |
Max compatible fork travel | See service manual |
Hub front | Shimano TC500 alloy, CentreLock, 110x15 mm thru axle |
Hub rear | Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
Skewer rear | Bontrager Switch thru-axle, removable lever |
*Rim | Size:S , M , L , XL Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
Size:S , M , L , XL Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve |
Spokes | 14 g stainless steel, black |
*Tyre | Size:S Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40" |
Size:M , L , XL Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40" |
Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
Rim strip | Bontrager TLR |
Max tyre size | Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer |
Battery | Bosch PowerTube 600 Wh, smart system |
Charger | Bosch standard 2A, 230V, smart system |
Computer | Bosch Purion 200 |
Motor | Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
Shifter | Shimano U6000, 10-speed |
Rear derailleur | Shimano CUES U6000 GS |
Crank | FSA Bosch CK-220, 36T ring, 165 mm length |
Chainring | FSA, 36T, steel |
Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
Chain | Shimano LG500, 9/10/11-speed |
Pedal | VP-536 nylon platform |
Max. chainring size | 1x: 38T |
Saddle | Bontrager Verse P3, steel rails |
*Seatpost | Size:S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
Size:M , L , XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
Handlebar | Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
Grips | Bontrager XR Trail Comp, nylon lock-on |
Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
Brake | Tektro Gemini SL 4 piston hydraulic brake |
Brake rotor | Tektro, CentreLock, 203 mm |
Rotor size | Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer |
Mudguard | Trek 27.5" custom fender |
Weight | M – 24.58 kg/54.19lb (with TLR sealant, no tubes) |
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
