Frame
OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post-mount brake, Boost148
Fork
RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Suspension part
Bontrager Drop Lock remote
Wheels
Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Skewer rear
Bontrager Switch thru axle, removable lever
Tyre
Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tyre size
Frame: 29x2.40", Fork: See manufacturer
Shifter
SRAM Eagle 70, 12-speed
Rear derailleur
SRAM Eagle 70, T-Type
Crank
Size: ML , M , S Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length; Size: L , XL Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 175 mm length
Bottom bracket
SRAM DUB, 92 mm, PressFit
Cassette
SRAM Eagle XS-1270, T-Type,10-52, 12-speed
Chain
SRAM Eagle 70, T-Type, 12-speed
Max. chainring size
1x: 38T
Saddle
Verse Short Comp, steel rails, 145 mm width
Seatpost
Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length; Size: ML , M , L Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length; Size: XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Size: S Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width; Size: ML , M , L , XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Trek Line Comp, nylon lock-on
Stem
Size: S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length; Size: ML , M Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length; Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length; Size: XL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake rotor
SRAM CenterLine, 6-bolt, round-edge, 160 mm
Rotor size
Max brake rotor sizes – Frame: 180 mm, Fork: see fork manufacturer
Tool
Bontrager Switch Lever, w/tool
Weight
M - 11.83 kg / 26.09 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
